Sensotek. Intelligent Sensor Solutions.

secuENTRY 7171 RELAY

This product is currently not available.
Total price: €321.30
Net price: €270.00

Prices incl. VAT plus shipping costs

Availability Delivery time approx. 5 working days

Not in stock
  • 10001156
Questions to the product?
Talk to us: +49 7163 93926-77
Volume discounts on request by phone
Relay for switching of gates or barriers Do you want to open your garage door electrically?... more
Product information "secuENTRY 7171 RELAY"

Relay for switching of gates or barriers

Do you want to open your garage door electrically? Or the gate to your courtyard entrance? Then simply integrate the corresponding door into the secuENTRY pro locking system! The secuENTRY 7171 relay makes it possible. The switching unit sends the corresponding signal to open or close the gate. Of course, there are many other possible applications. Any external electrical device can be switched with the relay. For example, rolling gates or barriers. Furthermore, light sources can also be controlled via the switching unit.

The secuENTRY 7171 relay can be activated in various ways. By pin code or finger scan via the secuENTRY pro keypad as well as via the sE-Key active transponder. Of course, switching via the secuENTRY KeyApp is also possible. Incidentally, the data is received via modern Bluetooth 5.2 and is secure thanks to AES encryption. The switching unit is installed in a weatherproof and tamper-proof area. Important: No voltage of 230 volts may be switched via the relay 7171. The maximum voltage is 24 volts. To teach-in the secuENTRY 7171 relay, simply use the QR code enclosed in the packaging.

Using the optional secuENTRY software, you can equip the relay with time functions and assign opening rights. This means you always have an overview of who is allowed to use the functions of the secuENTRY 7171 relay and who is not.

Technical specifications:

  • Transponder: Aktiv, Smartphone
  • Communication: Bluetooth 5.2
  • Output: Relay, NO, NC
  • Switching voltage: max. 24 V, 1 A

Replacement for secuEntry 7071 Relay, p.n. 130-0006
