ShieldScan-3M-SSR

€665.00

Gross price incl. 19% Vat., plus shipping,
Net price plus 19% Vat., plus shipping

Availability: Estimated delivery time: 1-3 days
4 articles available

Stück

Product number: 70114100-100019

Product information "ShieldScan-3M-SSR "

Safety Sensor for Automatic Swing Doors

The ShieldScan-3M-SSR is a solid-state scanner designed for person protection on automatic doors. Its integrated Time-of-Flight (ToF) technology enables reliable monitoring of the door area. The sensor is particularly designed for use on automatic swing doors.

With one sensor installed on each side of the door, the ShieldScan-3M-SSR creates a continuous detection field. The sensor monitors the main closing edge, door leaf and secondary closing edge. If the light beams are interrupted by a person or object, the corresponding switching outputs are triggered.

The SSR version features a solid-state relay output (SSR) and is therefore suitable for applications requiring an SSR output for connection to the door control system.

Closing-Edge Protection and Anti-Collision Protection

The ShieldScan-3M-SSR is designed for closing-edge protection on automatic door systems. In addition to the main closing edge, the safety sensor monitors the door leaf and the secondary closing edge.

This enables the sensor to support the protection of people and objects within the movement area of automatic doors. The ShieldScan-3M-SSR can also be used for anti-collision protection near moving swing or revolving doors.

The secondary closing edge is monitored using a curved beam field. This allows lateral reaching around the door leaf to be detected as well.

ToF Technology and Virtual Wall Function

The ShieldScan-3M-SSR uses Time-of-Flight technology and features 20 beams. The integrated Virtual Wall function enables dynamic, angle-dependent adaptation of the detection field.

As the door opens, the individual beams of the detection field are masked according to the opening angle. This allows changes behind the opened door to be taken into account during detection.

Easy Installation and Commissioning

The ShieldScan-3M-SSR is designed for plug-and-play corner mounting. The integrated One-Teach function supports quick and easy commissioning.

The compact housing allows the sensor to be discreetly integrated into the door system. With its IP65 protection rating, the sensor is suitable for applications where protection against dust and water is required according to the specified IP rating.

The sensor is designed for installation heights of up to 3000 mm. Depending on the installation height and door width, the applicable operating ranges specified in the technical data sheet must be observed.

Technical Features of the ShieldScan-3M-SSR

Solid-state scanner with Time-of-Flight technology
20 beams
Solid-state relay output (SSR)
People and object detection
Closing-edge protection for automatic door systems
Monitoring of the main closing edge, door leaf and secondary closing edge
Virtual Wall function
One-Teach function
Plug-and-play corner mounting
IP65 protection rating
Operating voltage: 24 V DC ± 20%
SIL 2
Performance Level d
Category 2
Response time ≤ 50 ms at an installation height of up to 2500 mm
Ambient temperature: -30 °C to +60 °C
Black housing

FAQ about the ShieldScan-3M-SSR

What types of doors is the ShieldScan-3M-SSR suitable for?

The ShieldScan-3M-SSR is designed for person protection on automatic door systems and is particularly suitable for standard automatic swing doors. It can also be used for anti-collision protection near moving swing or revolving doors.

Which areas does the ShieldScan-3M-SSR monitor?

The sensor monitors the main closing edge, door leaf and secondary closing edge. This creates a continuous detection field on the respective side of the door.

What does SSR mean in ShieldScan-3M-SSR?

SSR stands for Solid State Relay. The ShieldScan-3M-SSR features a solid-state relay output for connection to the door control system.

What protection rating does the ShieldScan-3M-SSR have?

The ShieldScan-3M-SSR has an IP65 protection rating.

Which standards are specified for the ShieldScan-3M-SSR?

The ShieldScan-3M-SSR is specified with standards including EN 16005 and DIN 18650. ISO 13849-1 and EN 61508 Parts 1–4 are also specified in connection with functional safety.
